Infrared Human Body Sensor, LED Light Sensor Switch, DC 5V-24V Motion Detector Sensing Distance 1-3 Meters

Item ID: GY19892

5 9

Price: ~~$6.99~~ $4.89

Time Remaining:

Quantity: - OR - - OR - Add to Wish List

Prev: DC 8V-24V Hand Sweep Sensor Infrared Swing Sensor Switch Sensing Distance 10cm
Next: Human Infrared Sensor Module with Lens

1.Description:

It is a infrared human body sensor.It has a built-in photosensitive chip,and the sensing function will be turned off when the external environment is bright.Therefore,the sensor will not trigger the sensing function under normal daytime conditions.

When the photosensitive chip senses that the external environment is dark,it will automatically turn on the infrared sensing function.At this time,if someone enters the sensing area,the sensor will trigger.

2.Feature:

1).It has a delay time knob,which can adjust the delay time from 10 seconds to 15 minutes.

2).It has a light control function,which automatically switches and adjusts according to the ambient brightness.

3).It uses infrared pyroelectric,which is accurate in sensing.

4).It is suitable for LED lights.

5).Its sensing angle is 120°,which belongs to the general sensing range.

3.Parameter:

1).Product Name:Infrared Human Body Sensor

2).Working Voltage:5-24V

3).Maximum Current:3A

4).Sensing Angle:120°

5).Sensing Distance:1-3 meters

6).Adjustable Delay time:10s-15 minutes

7).Function:with light control (no light during the day,sensing light at night or in a dark environment)

8).Work Temperature:-25℃~85℃

9).Work Humidity:5%~95%RH

10).Size:48*37*30mm

4.Package:

1pcs Infrared Human Body Sensor
