JF-0530B DC12V 300mA 5N/10mm Pull-Push-Type Solenoid Electromagnet

$3.39
$4.9932%
Quantity50+
Price$3.50
00d : 00h : 00m : 00s
Item ID: 7404
Add to Cart
Share

Product Details

Specifications:
Product Name: DC Solenoid Electromagnet
Model: JF-0530B
Rated Voltage: DC 12V
Type: Pull Push
Rated Current: 300mA
Force& Stroke: 5N/10mm
Body Size: 30x16x15mm
Plunger Bar Size: 6x58mm
Mounting Hole Dia.: 2.5mm
Cable Length: 20cm
Material: Metal, Electronic Parts

Description:
1. Pull push type, linear motion, plunger return, DC solenoid electronmagnet.
2. DC Solenoid Electromagnet mainly used in vending machines, transport equipment, office facility  household appliance, mechanical, etc.
3. Solenoids of this category work externally through pulling pushing in plunger.
4. When energized, doing work through pulling pushing in plunger joined object.

Note:Please don't power for a long time.Just about seconds.
