2.4GHz CC2520 Controller Development Board for ZigBee Wireless Transceiver Module SMA Antenna Socket
$4.89$6.9930% (only 0 pcs )
00d : 00h : 00m : 00s
Item ID: GY16695
Product Details
1.Description:
The CC2520 is TI's second generation ZigBee IEEE 802.15.4 RF transceiver for the 2.4GHz unlicensed ISM band. This chip enables industrial grade applications by offering state-of-the-art selectivity/co-existence, excellent link budget, operation up to 125°C and low voltage operation.
In addition, the CC2520 provides extensive hardware support for frame handling, data buffering, burst transmissions, data encryption, data authentication, clear channel assessment,link quality indication and frame timing information. These features reduce the load on the host controller.
In a typical system, the CC2520 will be used to gether with a microcontroller and a few additional passive components.
2.Feature:
1>.State-of-the-art selectivity/co-existence
2>.Excellent link budget (103dB)
3>.Extensive IEEE 802.15.4 MAC hardware support to offload the microcontroller
4>.CC2420 interface compatibility mode
3.Parameter:
1>.Model: SM12Z2520
2>.Work Voltage:1.8V-3.8V
3>.Output Power:5dBm(Max)
4>.Sensitivity:-98dBm
5>.RAM:768Byte
6>.FIFO:128Byte
7>.Work frequency:2394MHz-2507MHz
8>.Work Rate:250kbps
9>.Work Temperature:-25℃~85℃
10>.Work Humidity:5%~95%RH
11>.Size:48*24*11mm
4.Package:
1>.1pcs 2.4GHz CC2520 Controller Development Board
2>.1pcs Antenna
