40Bit WS2812B 5050 RGB LED Driver Module Programmable LED Lamp Matrix for UNO R3
Product Details
1.Description:
WS2813B is an intelligent external controlled LED light source integrating control circuit and light emitting circuit. Its appearance is the same as a 5050LED lamp bead, each component is a pixel point.
Inside the pixel contains an intelligent digital interface data latch signal shaping and amplifying drive circuit, also contains a high-precision internal oscillator and 12V high voltage programmable fixed current control part, effectively ensure the pixel light color is highly consistent.
2.Feature:
1>.Smart reverse protection, power supply reverse polarity will not damage the IC;
2>.IC control circuit and a power LED spot light utility;
3>.The control circuit chip and RGB components in a package in 5050, to form a complete external control pixels;
4>.Built-in signal shaping circuit, any one pixel after receiving the signal through the waveform shaping and then output to ensure line waveform distortion will not accumulate;
5>. Built-in power-on reset and brown-out reset circuit;
6>.Trichromatic color of each pixel can realize 256 high lighted, complete 16777216 colors of all true color display, the scanning frequency is not less than 400Hz/s;
7>.Serial cascade interface, through a signal line to complete the receiving and decoding of data;
8>.Biography transmission distance between any two points in less than 5 meters without any additional circuitry;
9>.When the refresh rate of 30 frames/s, cascading number of not less than 1024 points;
10>.Data transmission speed of up to 800Kbps;
11>.Light color highly consistent, cost-effective.
3.Parameter:
1>.Model: WS2812B
2>.Work Voltage: 5V
3>.Work Temperature: -25℃~85℃
4>.Work Humidity: 5%~95%RH
5>.Size: 56x53mm
4.Application:
1>.LED full color light word string, LED full color module, LED full color soft light strip hard light strip, LED guardrail tube;
2>.LED point light source, LED pixel screen, LED shaped screen, all kinds of electronic products, electrical equipment running lamp.
5.Package:
1pcs 40Bit WS2812B 5050 RGB LED Driver Module.
