5PCS LM259 Mini-360 DC to DC 4.75V-23V to 1V-17V Buck Converter Step Down Power Supply Module 340KHz
$3.33$4.7530%
| Quantity | 5+ | 10+ | 30+ |
| Price | $3.30 | $3.10 | $2.80 |
00d : 00h : 00m : 00s
Item ID: 12363
Product Details
Description:
- Model Name: Mini-360 (ultra small size DC-DC synchronous rectifier buck module)
- Module Properties: non-isolated buck
- Rectification: synchronous rectification
- Input voltage: 4.75V-23V
- Output voltage: 1.0V-17V
- Output Current: lowering the value of 3A, long 1.8A
- Conversion efficiency: 96% (maximum)
- Switching Frequency: 340KHz
- Output ripple: 30mV (no-load)
- Load regulation: +/- 0.5%
- Voltage regulation: +/- 2.5%
- Working temperature: -40 ℃ to +85 ℃
- External dimensions: 17 * 11 * 3.8 (L * W * H) (mm)
- Features: Use integrally molded power inductor and synchronous rectifier control chip, smaller and more efficient.
Tested by ICStation's Outstanding Partner Hugatry's HackVlog:
