ICStation DIY Airplane Flashing LED Kit for STEM Learning Home Education - First Soldering Projects for DIYers Students Beginners

1.Introduction:
It is an Airplane Flashing LED Circuit Electronic Kit. It can simulate the flickering effect of airplane lights and create a very artistic desktop decoration.

【Soldering Learning】 The airplane kit includes a few DIP components and 7 LED flashing lights, making it suitable for beginners to grasp basic circuit knowledge and practice soldering skills. Follow the detailed instruction manual, it takes approximately an hour for you to complete the soldering of this kit. The soldering process is relatively simple, making it an ideal choice for beginners. Please pay attention to the polarity of the components during soldering.

【School Education】This airplane kit can be served as a part of DIY projects, igniting students' creativity and interest in electronic devices. It can also be utilized in Science, Technology, Engineering, and Mathematics (STEM) courses, assisting students in applying theoretical knowledge to practical scenarios.

【Creative Gift】 You can personally solder and DIY an airplane flashing kit as a unique gift to surprise your loved one. Alternatively, spend a memorable time with your son, daughter or grandson during a special soldering practice. Place it in the living room or on a desk, and it will become an exquisite decoration!

【Detailed Installation Manual】 No need to worry about soldering operations. We've prepared a detailed graphic manual for you, both in PDF and Paper Instruction available. Refer to the manual, follow the steps patiently. If any issues during the assembly, feel free to contact us.

2.Parameter:
1>.LED color: Red/Green/Yellow
2>.Battery type:CR1220 lithium battery (included)
3>.Work Temperature:-20℃~85℃
4>.Work Humidity:0%~95%RH
5>.Size(Installed):110x105x33mm

3.Component listing:
   1pcs DIP-16 CD4017BE decimal counter at U2.
   1pcs DIP-8 NE555P timer at U1.
   1pcs DIP-16 IC Socket at U2.
   1pcs DIP-8 IC Socket at U1.
   1pcs 1Kohm Metal Film Resistor at R3.
   1pcs 5.1Kohm Metal Film Resistor at R2.
   1pcs 10Kohm Metal Film Resistor at R1.
   3pcs 3mm Red LED at LED1, LED4, LED7.
   2pcs 3mm Green LED at LED2, LED3.
   2pcs 3mm Yellow LED at LED5, LED6.
   1pcs 0.01uF 103 Ceramic Capacitor at C2.
   1pcs 10uF Electrolytic Capacitor at C1.
   1pcs Power Switch at SW.
   1pcs CR1220 lithium battery at BT1, BT2.  (Watch kids under 6 carefully)
   1pcs CR1220 lithium battery socket at BT1, BT2. (Watch kids under 6 carefully)
   2pcs PCB circuit board
