CT14 Mini Stereo Amplifier Module Bluetooth-compatible 5.0 Power Amplifier Board Module 5VF 5W+5W with Micro USB Charging Port
$4.19$5.9930%
| Quantity | 10+ | 30+ | 50+ |
| Price | $3.99 | $3.80 | $3.65 |
00d : 00h : 00m : 00s
Item ID: 13079
Product Details
Description:
This product is a stereo Bluetooth amplifier module. Ideal for DIY portable Bluetooth speaker.
It is able to give your amplifier/home stereo Bluetooth capability, just a very simple operation can be converted into Wireless audio. You don't need to be tethered by a cord when you play music through the wireless Bluetooth input.
Supports anti cracking sound function and subwoofer enhancement.
Features:
★ The earlier version is 4.2, now it has been updated to 5.0 version. It can be compatible with all mobile phones and Bluetooth adapters on the market.
★ 15 meters transmission distance in open space.
★ Support automatically connecting devices that have been paired and playing music automatically.
★ F class power amplifier 5W+5W dual channel stereo audio, over 8002 sound quality.
★ Supports USB sound card, no need to drive, just plug and play.
★ Subwoofer Enhancement.Suitable for upgrading and refitting the idle sound box and DIY production.
Instructions:
1>. Support USB sound card, free drive, plug and play (normal lithium battery power supply situation).
2>. This product has dual 5W power amplifier circuit. It can not be used in addition to the power amplifier. The output of two amplifiers can not be connected in parallel or connected to the negative electrode, otherwise the power amplifier chip will be damaged.
3>. There are two 2-8 European and 3-10W speakers respectively, and 3 European 5W and 4 European 10W horn are used. The output is stereo.
4>. Maximum working current is 5V 2A, sound quality will be better when using 5V 2A or more voltage power supply.
You may need a charging board when making a wireless speaker.
Recommend for using the ICStation TP4056 Micro USB 5V 1A Charging Board (Item ID: 12620)
5>. It is suggested that a 3.7-5V lithium battery (the lithium battery needs a protective plate! It can charge a lithium battery with a USB rechargeable battery, and the USB port can not be used as a power supply port.) or a 5V adapter be used for power supply. It can not use voltage and current unstable power supply, such as dry battery, portable charger, multi-function transformer and so on.
6>. When the Bluetooth board is installed, the antenna should not be close to the metal parts so as not to affect the transmission distance.
Operation:
Start the cell phone Bluetooth, scan the device, find the "DW-CT14+" to click connection.
Note:
The charging interface of this product is a current limiting charging mode without charge management. For your safety, be sure to use a regular lithium-ion battery with a protective plate, which can cause loss due to improper use.
The on-board USB interface can not only be used to USB sound card but also charge the lithium battery and also used as a 5V power supply port.
But please don't use the power supply with unstable voltage and current, such as dry battery, portable charger, multi-function transformer and so on
But please don't use the power supply with unstable voltage and current, such as dry battery, portable charger, multi-function transformer and so on
Package List:
Main board + plug line
