12V DC Digital Temperature Controller, WiFi APP Control High Temperature Control Module -99°C~999°C 24V Thermostat Control Switch Board with 10A One-Channel Relay Waterproof K-Type Thermocouple Probe
$15.39$21.9930%
00d : 00h : 00m : 00s
Item ID: GY20338
Product Details
How To Connect To The APP
Module Pairing
Download and register APP Sinilink.
Connect to DC6V-30V power supply at input terminal. (Note: Please don’t connect to load before pairing and test.)
Make sure the module and phone are connected to the same WIFI. Note: It can work with 2.4G WIFI instead of 5G.
Pressing the button on WIFI module 5 seconds and it will enter into pairing mode.
APP Pairing
Click + on the right and select "Touch".
The WIFI name is automatically displayed and then enter the WIFI password which phone is connected. And then the next step.
Set device name and classification. And then the next step.
Waiting configuration about 1~3minute.
If the pairing fails, please try it several times (remove power supply).
Reset the module device name after connecting successfully.
Finished. You can test and set module parameters.
Specifications and Parameters
Product Name: Digital High Temperature Controller
Working Voltage: DC 6-30V
Maximum Current: 10A
Temperature Control Range: -99°C~+999°C
Temperature Measurement Accuracy: ±2°C
Output Type: One-Channel Relay Switch
Probe Type: K-Type Thermocouple
APP real-time monitoring and setting
Temperature correction
Emergency stop
Clear LCD display
High and Low Temperature Alarm APP Real-time Monitoring Shared by Multiple People
Precision Welding Built-in WiFi Module Waterproof K-Type Thermocouple Probe
