1.Description:
XY-ST10 is an automatic timed heating/cooling NTC digital temperature controller module. It can be widely used at smart home,Industrial control, Automatic irrigation,Indoor ventilation,Protection equipment.
XY-ST10 adopts industrial-grade chip with high-precision NTC temperature sensor that can measuring -40℃~110℃ or -40℉~166℉.

2.Features:
1>.Heating/cooling automatic control
2>.Celsius and Fahrenheit switch display
3>.Automatic control output status
4>.Simultaneous temperature detection
5>.Automatic recognition working mode
6>.High and low temperature automatic alarm
7>.Automatic data saving
9>.High temperature measuring -40C~110C or -40F~116F
9>.ABS standard size housing
10>.10A relay switch output
11>.HD LCD Display Screen
12>.Power saving mode
13.Programmable display temperature calibration

3.Parameters:
1>.Working Voltage:DC 6V-30V
2>.Control Type:Button
3>.Sensor(Include):NTC 10K 3980B(2 meter)
4>.Sensor(Support):DS18B20(Not Included)
5>.Temperature Range:-40C~110C or -40F~110F
6>.Temperature Control precision:0.1C/F
7>.Output Type:Relay output(It can not output voltage)
8>.Load: AC220V/DC30V 10A
9>.Additional function:Buzzer Alarm
10>.PCB Working Temperature range:-40℃~85℃
11>.Working Humidity Range:5%-95%RH
12>.Module Size:79*43*25mm

4.Application:
1>.Control cabinet
2>.Production workshop
3>.Hatching aquaculture control
4>.Tobacco industry
5>.Printing house
6>.Aquarium temperature control
7>.Wood fired boiler

5.Note:
1>.It is a relay output mode and cannot be used as a power module. It cannot output voltage. The load needs to be connected to a separate power supply.
2>.Buzzer will alarm if no sensor was connected.
3>.Please read use manual and description before use.

6.Package:
1>.1pcs XY-ST10 Automatic Timed Heating/Cooling Temperature Controller
2>.1pcs 2meter NTC 10K 3980B temperature sensor

7.User Manual:
