• DC 8V-24V High Power Digital Amplifier Module Mono Class D 4-8ohm for 30W-300W speaker
  • DC 8V-24V High Power Digital Amplifier Module Mono Class D 4-8ohm for 30W-300W speaker
  • DC 8V-24V High Power Digital Amplifier Module Mono Class D 4-8ohm for 30W-300W speaker
  • DC 8V-24V High Power Digital Amplifier Module Mono Class D 4-8ohm for 30W-300W speaker

DC 8V-24V High Power Digital Amplifier Module Mono Class D 4-8ohm for 30W-300W speaker

$4.89
$6.9930%
00d : 00h : 00m : 00s
Item ID: 13495

Product Details

1.Description:
    DY-AP3001 is a high-power mono Bluetooth audio module.Single channel audio signal output.Built-in amplifier module therefore it can connect to loudspeaker directly.It is ideal for DIY speakers and transponders.

2.Features:
    1>.Width work voltage range
    2>.Applicable multiple type speakers
    3>.Support enabled/disabled output

3.Parameters:
    1>.Product name:DY-AP3001 Digital Amplifier Module
    2>.Model:DY-AP3001
    3>.Work Voltage:DC 8V-24V
    4>.Work Mode:Class D
    5>.Channel:Mono
    6>.Input:Audio input
    7>.Output Power:
        7.1>.Output power 30W at 16V 4ohm
        7.2>.Output power 20W at 12V 4ohm
        7.3>.Output power 10W at 12V 8ohm
        7.4>.Output power 15W at 16V 8ohm
        7.5>.Output power 25W at 24V 8ohm
    8>.Match speaker(30W~300V):
        8.1>.4ohm at 8V~16V
        8.2>.8ohm at 8V~24V
    9>.Work Temperature:-40℃~85℃
    10>.Work Humidity:0%~95%RH
    11>.Module Size:26*22*10mm

4.Use steps:
    1>.Choose the right speaker and connect as shown in wiring diagram.
    2>.Connect to right power supply from input terminal.

5.Application:
    1>.Modified speaker
    2>.Amplifier equipment
    3>.Car device

6.Note:
    1>.Pay attention to static electricity protection.
    2>.Recommended power supply voltage DC 8~24V.Module will be damaged if input voltage is more than 26V.
    3>.Input voltage can not more than 16V if connect 4ohm speaker.
    4>.Input voltage can not more than 24V if connect 8ohm speaker.
    5>.It is recommended to use a power supply of 2A or higher.
    6>.The positive and negative poles of the input power supply cannot be reversed Otherwise the module will be damaged.
    7>.Please don’t use too long wires to avoid signal interference.
    8>.It is recommended to use a speaker above 30W to avoid speaker damage.
    9>.Please read use manual and description before use.

7.Frequently asked questions:
    1>.Speaker ‘pu~’ after power ON and then no response.
        1.1>.Try to reduce the input voltage to restart.
        1.2>.Check if the speaker impedance is 4ohm~8ohm.Maybe the impedance is too small.
        1.3>.Check power.Make sure its input current is more than 2A.
    2>.There is noise during playback.
        2.1>.Change the sound source and check if the sound source has its own noise.
        2.2>.Use shielded audio cable.
        2.3>.Change speaker.
        2.4>.Change power adapter.
    3>.Module get hot and smoke.
        3.1>.Speaker power is too small.Change high power speakers or reduce signal input.

8.Package:
 1pcs DY-AP3001 Digital Amplifier Module


Customer Reviews (0)
