Industrial USB to RS485 Converter Communication Module TVS Transient Protection

$3.49
$4.9930%
00d : 00h : 00m : 00s
Item ID: 13504

Product Details

1.Description:
    ZK-U485 is a Industrial grade USB to RS485 communication module.
    Two-way communication half duplex serial port.
2.Features:
    1>.Support TVS transient suppression protection
    2>.Support electrostatic ESD protection
    3>.Support surge protection
    4>.Support short circuit protection
    5>.Super long communication distance
    6>.Support hot plug and unplug
    7>.Automatically determine and control the data transmission direction
    8>.Support XP/WIN7/WIN8/WIN10/VISTA/LINUX/MAC OS X operating system

3.Parameters:
    1>.Product name:ZK-U485 CH340 USB to RS485 Converter
    2>.Model:ZK-U485
    3>.Work Voltage:DC 5V
    4>.Communication distance:1200meter(Max at 9600bps)
    5>.Baud rate:115200bps(Max)
    6>.Work Temperature:-40℃~80℃
    7>.Work Humidity:0%~95%RH
    8>.Module Size:70*27*13mm

4.Use steps:
    1>.Download CH340 Driver software and Serial communication software.
    2>.Install CH340 Driver.
    3>.Connect module to PC and check PC’s ‘Device manager’.It will display CH340.If the computer does not recognize module, user need to uninstall the driver software, then re-install or replace the computer or change USB port.
    4>.Open Serial communication software to use send data.

5.Application:
    1>.Data collection
    2>.Signal conversion
    3>.Equipment Repair
    4>.Product development

6.Package:
1pcs ZK-U485 USB to RS485 Converter
