Intelligent Offline Speech Recognition Module Voice Recognition Control Switch Lights Chip Sound Control SU-10A Module
$4.89$6.9930%
| Quantity | 3+ | 6+ | 10+ |
| Price | $4.85 | $4.70 | $4.55 |
00d : 00h : 00m : 00s
Item ID: GY19551
Product Details
1.Description:
It is a offline speech recognition module. SU-10A is a low-cost, low-power, small-size offline voice recognition module, which can be quickly applied to smart homes, all kinds of smart home appliances, toys, lamps and other products that require voice control.
2.Feature:
1).32bit RISC core,running frequency 240M.
2).Support DSP instruction set and FPU floating point arithmetic unit.
3).FFT accelerator:supports up to 1024 points of complex FFT/IFFT operations,or 2048 points of real FFT/IFFT operations.
4).Built-in high-speed SRAM,built-in 2MB FL ASH.
5).Built-in 3W,mono AB power amplifier.
6).Support 1 electret microphone.
7).Support 5V power input.
8).The default voltage of the UART interface is 5V,and it can also support 3.3V.
3.Parameter:
1).Product Name:Offline Speech Recognition Module
2).Connection method:PH2.0mm pitch connector
3).Support interface:UART/MIC/SPEAKER
4).Average Working Current:60mA
5).Power Supply Voltage: 3.6V-5.5V
6).Supply Current:200mA(Min)
7).Work Temperature:-20℃~85℃
8).Work Humidity:5%~95%RH
9).Size:33*28*9mm
4.Support speaker specifications:
1.Under VCC=5V,4ohm load,it provides up to 2.9W output power
2.Under VCC=5V,8ohm load,it can provide up to 1.8W output power
5.Package:
1pcs Offline Speech Recognition Module
