IP6505 4USB Charging Module for QC2.0 QC3.0 FCP AFC USB Charger

$5.78
$8.2530%
00d : 00h : 00m : 00s
Item ID: GY21141-1

Product Details

1.Description:
 The charging module can quickly charge other devices, it supports a variety of quick charge.

2.Feature:
 1>.It supports BC1.2 and Apple protocols.
 2>.It supports Huawei fast charging protocol FCP, SCP.
 3>.It supports Samsung fast charging protocol AFC.
 4>.It supports for Spreadtrum Fast Charge Protocol SFCP.
 5>.It supports Qualcomm QC2.0 and QC3.0.
 6>.It supports MTK PE1.1/PE2.0.
 7>.Four interfaces can output simultaneously.
 8>.The output interface is type-A.
 9>.Its step-down conversion efficiency up to 97%.

3.Parameter:
 1>.Model:IP6505 4USB Charging Module.
 2>.Product Power: 24W.
 3>.Color:blue.
 4>.Input Voltage:4.5V~32V.
 5>.Output Voltage:3V~12V.
 6>.Output Power:24W (MAX).
 7>.Work Temperature:-25℃~85℃.
 8>.Work Humidity:5%~95%RH.
 9>.Size:90x60mm.

4.Intructions for Use:
 1>.It can be powered by a 5.5*2.1mm power socket, or you can weld the power supply on your own.
 2>.The range of input voltage is 4.5~32V, the maximum output voltage is 12V 2A.
 3>.After powered the blue indicator lights up, and then you can connect electrical equipment.
 4>.Examples of output voltages and currents are 4V/3.6A, 5V/3.4A, 7V/3A, 9V/2.5A, 12V/2A.

5.Package:
 1 pcs IP6505 4USB Charging Module.
