DIY Kits 15kV High Voltage Pulse Generator Arc Ignition Coil Module 3.7-4.2V
$2.51$3.5930%
| Quantity | 5+ | 10+ | 30+ |
| Price | $2.49 | $2.45 | $2.33 |
00d : 00h : 00m : 00s
Item ID: 11217
Product Details
Product Introduction:
1.Input Voltage:3.7-4.2V
2.Input Current: ≤ 2A
3.Output Voltage:≤ 15kV
4.Output Current: ≤0.4A
5.High Voltage Polarization Ignition Distance: ≤ 0.5cm
6.Size: About 20mm * 17mm * 16mm (L * W * H, irregular size, the longest length to measure)
7.There are two primary coil pin transformers. The thick copper wire is transformer main pin, and the thin copper wire is Transformer Feedback Pin.
8.The middle of the two copper wire is positive. They are respectively Transformer Pin tail and feedback pin head. The positive connects red wire.
7.There are two primary coil pin transformers. The thick copper wire is transformer main pin, and the thin copper wire is Transformer Feedback Pin.
8.The middle of the two copper wire is positive. They are respectively Transformer Pin tail and feedback pin head. The positive connects red wire.
Packing List:
15KVE-1 Stap-Up Coil:1pc
200 ohm Resistor:1pc
FR107 Diode:1pc
Triode:1pc
Insulated Wire:1pc
Attention:
1.After you finish the transformers, you need keep the product under epoxy resin or insulation wax encapsulation if you want to keep it for a long time.
Because the product will be due to lack of air insulation strength of the coil breakdown caused by damage in the air work.
1.After you finish the transformers, you need keep the product under epoxy resin or insulation wax encapsulation if you want to keep it for a long time.
Because the product will be due to lack of air insulation strength of the coil breakdown caused by damage in the air work.
2.The kit is used for 3.7V input voltage (That is one 18650 charge power). If you want ro increase input voltage, you need to increase the resistor(the default resistor is 200 ohm).
If you don't increase the resistor, the triode is easily to be damaged. But you CAN NOT increase voltage over 12V.
Note: This DIY product can produce high pressure, just like electric mosquito swatter...if you touch it with your hand directly, you will have electric shock feeling, this DIY kit also has the same working principle.
Diagram:
Tested by ICStation Outstanding Partner Hugatry's HackVlog and learnelectronics:
