DC 3.3V LPS22HB Atmospheric Pressure Sensor Module IIC SPI for Arduino
$5.45$7.7930%
00d : 00h : 00m : 00s
Item ID: GY15618
Product Details
1.Description:
The LPS22HB is a barometric sensor module. It can measure 500 meters from the sea floor to an altitude of 9000 meters in the air, and the accuracy can reach 10cm (1pa resolution), which is very suitable for floor positioning, weather station, GPS, wear and other equipment.
2.Feature:
1>.IIC communication protocol
2>.Ultra small volume
3>.High precision
4>.Built-in 16-bit temperature sensor
3.Parameter:
1>.Work Voltage:DC 1.7V~3.6V
2>.Signal output:24Bit
3>.Communication protocol: IIC
4>.Sampling frequency:1Hz~75Hz
5>.Atmospheric pressure range:26KPa~126KPa
6>.Work Temperature:-25℃~85℃
7>.Work Humidity:5%~95%RH
8>.Size:14*11*2.4mm
4.Package:
1>.1pcs DC 3.3V LPS22HB Atmospheric Pressure Sensor Module
2>.1pcs 4Pin Male Pin
3>.1pcs 4Pin Right Angle Male Pin
