DIY Kit NE555 Infrared Reversing Radar Sensor 30cm Distance Sensing Analog Circuit Electronic Soldering Kits
$2.79$3.9930%
00d : 00h : 00m : 00s
Item ID: GY20868-1
Product Details
1.Introduction:
TJ-56-109 is a NE555 Infrared Reversing Radar Sensor Electronic Soldering DIY Kit.
It simulates reverse radar sensing through infrared transceiver sensors to detect distance. Adjust RP1 distance and RP2 sensitivity.
LED3 is on when ranging is 30cm, LED2 and LED3 are on when ranging is 20cm, LED1 and LED2 and LED3 are on when ranging is 10cm.
It is a very interesting DIY electronic product which enables users to understand the circuit more clearly and learn soldering skills.
2.Feature:
1>.Adjustable sensitivity and measuring distance
2>.Simple and convenient operation
3.Parameter:
1>.Product Name: TJ-56-109 Infrared Reversing Radar Sensor DIY Kit
2>.Work Voltage:DC 9V
3>.Work Temperature:-40℃~85℃
4>.Work Humidity:5%~95%RH
5>.Size(Installed):80x60mm
4.Component Listing:
