ATX Power Adapter ATX Computer PC Power Board Power Supply
Product Details
1.Description:
It is a ATX power adapter board. It is suitable for some power amplifier boards,other electronic equipment,etc.
2.Feature:
1).It supports four groups of different power outputs.
2).It supports four sets of fuse protection.
3).It has a power indicator to display the working status of the module more intuitively.
4).It supports two control modes:toggle switch or second switch.
3.Parameter:
1).Product Name:ATX Power Adapter Board
2).Input Interface:Computer power ATX 20PIN or 24PIN
3).Output Voltage: +3.3V +5V -12V +12V +5V
4).Control Mode:Toggle switch or second switch
5).The Second Switch:can be used for the front panel,two pins are shorted to turn on the power
6).Work Temperature:-25℃~85℃
7).Work Humidity:5%~95%RH
8).Size:70*63*20mm
4.Note:
This adapter board only plays a role of power extraction,please do not exceed the power of the power supply in actual use to avoid damage to the power supply.
5.Package:
1pcs ATX Power Adapter Board
