RFID Wireless Reader Module 13.56MHz 125KHz Dual Frequency UART ID IC Card Reader
$5.59$7.9930%
00d : 00h : 00m : 00s
Item ID: GY17858
Product Details
Description:
- It is a IC+ID dual frequency card reader module.
- Integrates a high-performance card reader RF circuit and antenna, replacing the UART data output protocol.
Note:
Due to the shortage of the original chip, the product design has been changed to a new version since April 3rd, 2023. The function, size and interface did not change. Hope for your understanding.
Features:
- UART format output
- Support dual frequency RFID card
- Support ID+IC card
Parameters:
- Product Name: IC+ID Dual Frequency Card Reader Module
- Working Voltage: DC 5V
- Working Current: 40mA
- Support Reading:125kHZ and 13.56MHZ card reading
- Interface: UART
- Work Temperature: -35℃~85℃
- Work Humidity: 5%~95%RH
- Size: 47.5*27*5.5mm
4.Uart Interface Output Introduction:
Baud Rate: 9600
Data Header: 0x02
Length: 0x09
Card Type: 0x01
Card Number Data: SN0~SN3
BCC Check: XOR operation of other data except head and tail of data
End of Data: 0x03
The Card Types: 0x02 EM4100/0x01 MIFARE 1K
For Example: The data received by the serial tool is 02 09 02 04 2E 53 82 F0 03
The first byte 0x02 indicates the start of data.
The second byte 0x09 indicates that the entire data length is 9 bytes, including the start of data and the end of data.
The third byte 0x02 indicates that the card type is EM4100.
The 4th to 7th bytes (0x04 0x2E 0x53 0x82) These 4 bytes represent the card number read.
The 8th byte 0xF0 indicates the BCC check from the 2nd byte to the 8th byte.
The 9th byte 0x03 indicates the end of the data.
Applicable:
- Attendance fingerprint reader module
- Access control intercom card reader module
Package Included:
- 1pc IC+ID Dual Frequency Card Reader Module
- 1pc Wire
