1.Introduction:
CAI-C10 is LED Music Spectrum Flashing Electronic Clock Circuit Electronic Soldering DIY Kit. Automatically display the music spectrum when there is sound; Display the current time when there is no sound. Users can choose to switch between 18 music spectrum display modes and so on.
It can not only be used as a DIY electronic kit that allows you to better understand the circuit and learn how to soldering, but also as a very suitable experimental workbench tool.

2.Feature:
1>.18 Music Spectrum Display Modes
2>.Automatically Switch Between Spectrum and Clock
3>.Adjustable Audio Sensitivity
4>.Adjustable Display Brightness
5>.Nighttime Power-saving Mode
6>.12H/24H System Switchable
7>.Classic 8x8 LED Dot Matrix Display Screen
8>.Dual USB Power Supply

3.Parameter:
1>.Work voltage: DC 5V
2>.Display Color: Green
3>.Power Type: Micro USB
4>.Work Temperature:-40℃~85℃
5>.Work Humidity:5%~95%RH
6>.Size(Installed):128*32*18mm

4. User Manual:

More Details about the product:

Setting Methods:
