Product Introduction:
1. Operating Voltage: DC 9V-36V
2. With input reverse protection, output short circuit protection
3. Output voltage: 5.2V/5A/25W
4. Output capacity: 9-24V input: output 5.2V/6A/30W; 24-32V input: output 5.2V/5A/25W; 32-36V input: output 5.2V/3.5A/18W
5. Size: 70*40*30cm (L*W*H)
6. Applications: this module can be used for DIY modified cars, motorcycles, mobile power, battery USB charging port, to the phone, MP3 or other digital products charging.

Features:
1. Synchronous rectification scheme, wide voltage, high current, high efficiency;
2. With terminal blocks and DC plug, easy to use;
3. 4 USB ports, all with fast charging identification chip, compatible with Android Iphone
4. With fine aluminum shell, easy to use

Notice:

The power module has 5A current, but this doesn't mean will be 5A current charge to the phone. The charging current is determined by the power supply IC inside the phone

Why the output is 5.2V instead of 5V?

Because taking into account the charge line has 0.2-0.3V pressure drop, if the phone inside the voltage is only 4.7V, then its charge management software to detect the input voltage is less than 5V will open the slow charge mode. The output voltage at 5.2V, it will not appear above this situation.

1.Tested by ICStation's Outstanding Partner RC Tractor Guy:

Learn More Details from the Video:
(The language in the video is English)

2.Tested by ICStation's Outstanding Partner Lucid Dev Team:

Learn More Details from the Video:
(The language in the video is English)
