HW-XC508 Smart Sensor Switch Smart Home Microwave Sensor Module 5.8GHZ Microwave Sensor
$6.29$8.9930%
00d : 00h : 00m : 00s
Item ID: GY19753
Product Details
1.Description:
It is a HW-XC508 smart sensor switch.According to the principle of Doppler effect, it uses a planar antenna to send and receive high-frequency electromagnetic waves,and then detects a small movement change in the back wave, then triggers the microprocessor to work, and finally outputs a useful control level (H-1/L- 0) or control state.
2.Feature:
1).It is suitable for the secondary development of intelligent electrical appliances,security products,lighting products and other electronic fields.
2).It can be widely used in security monitoring,intelligent control systems,lighting appliances (uses in garages,corridors,roads,etc.).
3).Its static power consumption is low,only 15mA.
4).Its delay time and sensing distance can be adjusted.
5).Its sensing distance can reach 12 meters.
3.Parameter:
1).Product Name:HW-XC508 Smart Sensor Switch
2).Working Voltage:DC 6V-24V
3).Static Power Consumption:15mA(Max)
4).Output Mode:5V (with induction)/0V (without induction)
5).Trigger Mode:repeatable trigger
6).Transmission Frequency:5.8GHz
7).Delay Time:2-120s
8).Induction Distance:0.5-12meters
9).Work Temperature:-20℃~80℃
10).Work Humidity:5%~95%RH
11).Size:23.2*23.2*13mm
4.Specific Instructions:
1).Repeat trigger:After the first trigger,when the sensing area is triggered again,the module delay time will be superimposed again when the first trigger time has not stopped.(For example:the module delay time is 10s,the induction signal is received again within 10s,and then superimposed for 10s,the uninterrupted triggering within 10s,there will always be an output signal)
2).Delay time:refers to the duration of high voltage signal output.
5.Package:
1pcs Smart Sensor Switch
